SOM-iMX8X: NXP i.MX8X

Navigate

SOM-iMX8X: NXP i.MX8X

ARM
A35
4GB

NXP Freescale i.MX8X System on Module featuring high performance video and graphics capabilities and a wide range of high speed interfaces. Recommended for industrial HMI, digital signage, image processing and professional audio visual applications.

  • Quad Core ARM Cortex A35 @1.2GHz
  • Up to 4GB LPDDR4 and 64GB eMMC
  • 2 x LVDS, 2x MIPI-DSI, up-to 1080p60
  • WiFi 802.11ac, BT 4.2; 2x GbE, PCIe, USB2.0, 3x CAN-FD, 4x UART, 96x GPIO;
  • Wide tempature range -40° to 85°C
  • For industial HMI, image processing, digital signage
Send Enquiry
FeatureSpecification
CPU Architecture ARM Cortex A35
CPU Manufacturer NXP
CPU Model i.MX 8QuadXPlus Quad-core
CPU Frequency Up to 1.2GHz
Real Time Co-Processor Yes
MemoryUp to 4GB LPDDR4
Onboard Storage Up to 64GB eMMC
Display Interface 2x MIPI-DSI
2x LVDS
Display Resolution (Max) 1080p60
TouchScreen Controller CTP
Ethernet Ports 2
WIFI Certified 802.11ac Intel 8265 chipset
BluetoothV4.2 BLE
USB 2.0 Ports Host 1
MMC/SD/SDIO Up to 1
PCIe1x PCIe Gen. 3.0 * mutually exclusive with WiFi
UART/Serial Up to 4
GPIOUp to 96
I2CUp to 3
SPIUp to 4
Power Supply Voltage 4.0V – 4.5V
Dimensions 38 x 68 x 5 mm
OS Support Linux
Yocto Project File

* Optional feature available on this product

DocumentDescription
Block DiagramBlock Diagram for SOM-iMX8X
