4.3" Smart TFT Display with CTP and UART + GPIO
4.3" Smart TFT Display with CTP and UART + GPIO
Smart Display with UART interface. Easy-to-use product which allows customers to develop projects rapidly in a very cost-effective way. Designed with STM32 microcontroller which supports ST development tools like TouchGFX and STM32CubeIDE.
- 4.3'' IPS-TFT display
- UART interface + GPIO
- STM32F750 MCU
- Capacitive Touch Panel
- Wide all round viewing angl
- Protocol: Proprietary UART
| Feature | Specification |
|---|---|
| Part Number | 12175 |
| Screen Size | 4.3" |
| Resolution | 480 x 272 |
| Interface | UART |
| Protocol | Proprietary UART |
| Brightness | 400 cd/m2 |
| Touchscreen | Capacitive Touch Panel |
| MCU | STM32F750 |
| Flash Memory | 16MB |
| Viewing Direction | 85/85/85/85 |
| Operating Temperature | -30° to 80°C |
| Module Dimensions | 100 x 82 x 13.2mm |
| Active Area | 95.04 x 53.856mm |
* Optional feature available on this product
Development Kit
Kit Contents
- 4.3" Smart TFT Display
- USB-2 UART Dongle
- 4 pin Power/Data Cable
- USB to Micro USB Cable
- Kit Part Number: 12396
Designed with STM32 microcontroller which supports ST development tools like TouchGFX and STM32CubeIDE.
image shown is a 7.0" display
